Connect the Input Hose to the input pipe of the new Pump Module
and secure it using the hose clamp from the previous pump.
After the hoses are connected from the new pump:!
•
Secure the new charging dock with the 4 screws.
•
Secure the new pump module with the 4 screws.
•
Insert a charged SprayersPlus 20V battery.!
•
Put back the black plastic cover over the chamber and close
the white plastic door.!
You are all set !
NOTE:
Before having everything screwed onto the chamber, you
may consider to run a quick test: insert a charged 20V
SprayersPlus battery into the charging dock, put some water
into the tank, turn on the pump and spray for a little while.!
If there is leakage through the connections of the hoses you
have just connected, you can tighten the plastic nut, adjust
the host clamp, or even undo the hoses and re-connect
them until the leakage is fixed.
