Sprint Magic Box TREBL - Page 7

Page 7
Zigbee
No of Antenna: 1
Type: Dipole
Material: PCB
Frequency range: 2400 - 2500 MHz
ZigBee (802.15.4)
SIM card
Lab:
LAB/NRT devices will have 3FF removable UICC slots to use lab specific
UICCs
Production: MFF2 SIM (soldered) for production
MAC Address
Single MAC address for the complete board
Serial Number
SN rule: C+XX(Product ID) +YYMM(2 digits Year+2 digits
Month)+nnnnn (5 digits incremental hex number)
Product ID for MagicBox: C88
Ex: C88180612345
System
MB GPS will process AGPS data from Sprint provided file server
Device will do Plug and Play and receive new configuration at every Power
Cycle, including the case where a device moves between power cycles
Device has a System Watchdog Timer
Software + Hard ware
Disabled unused access ports
FCC Approved
LTE Femto Specification
The following table lists the LTE Femto specifications:
Category
Specification
Chipset Info
FSM9016 + FTR8930 + DDR3L1GB + AR8033
Transmit Power
2x 21dBm Max Indoor LTE Sector Tx Power
Antenna Gain
(Femto)
Band 41 Indoor Antenna Gain: > 5dBi
Tx Range
eNB Tx Dynamic Range: > 26dB
Tx Emissions
eNB Spurious Emissions: meet Category B as defined in 3GPP TS36.104
Rx Sensitivity
eNB Rx Sensitivity: meets Local Area as per TS36.104
Rx Selectivity
eNB Adjacent Channel Selectivity (ACL): as per TS36.104
Frequency
Accuracy
+/-0.1ppm eNB Frequency Accuracy
UE category
Support for UE Category up to 4
Bandwidth
Bandwidth support Single channel, B41, 10/15/20MHz
Transmission
Mode
Transmission Mode 3, 4
