Sprint Magic Box TREBL - Page 9

Page 9
Internet Protocol
(IP) support
IPv4 Support
IPv6 Support
Max UE’s
16 active UEs
Antenna Gain
WiFi Antenna Gain: >2dBi
GPS Antenna Gain: >2dBi
Receiver GPS
GPS Receiver as per spec
X2 AP procedure
Load information over X2
Congestion
control
Load based scheduling
LTE Relay Specification
The following table lists the LTE relay specifications:
Category
Specifications
SIM Card
Standard SIM Card (3FF) for Lab and MFF2 for production
Chipset Info
GDM7243A + GRF7243A + QCA8337
Band support:
B41 Low (2500MHz-2600MHz)
TDD: 41
B41 High (2620MHz-2690MHz)
FDD: 25
B25 (UL:1850Mhz-1915Mhz; DL:1930Mhz-1995Mhz)
TX Power
B41:23dBm
B25:20dBm
Antenna Gain (UE)
B41: 4dBi
B25: 6dBi
Modulation
UL: QPSK, 16QAM, 64QAM
DL: QPSK, 16QAM, 64QAM, 256QAM
CA
2CA, B25 any combination, noncontiguous
2CA, B41 Low any combination, Contiguous/noncontiguous
2CA, B41 High any combination, Contiguous/noncontiguous
3CA, B25 any combination, noncontiguous
3CA, B41 Low any combination, Contiguous/noncontiguous
3CA, B41 High any combination, Contiguous/noncontiguous
4CA, B41 Low
4CA, B41 High
MIMO
4x2 DL MIMO
4x4 DL MIMO (single carrier support only)
4x8 DL MIMO
SISO UL
2/4 TX CDD (UL)
Bandwidth
5/10/15/20Mhz
UE category
12
3GPP Release
R12
Disabled JTAG
Interfaces
Yes
Secure Bootable
Yes
