Page 5 of 7 IN018 Rev H
RB SERIES PRODUCT SPECIFICATIONS
The following chart shows fan performance for RB Series Commercial/Residential Fans:
Typical CFM Vs Static Pressure “WC
0” .2” .5” .75” 1.0” 1.25” 1.5” 1.75” 2.0”
RB110 135 100 68 10
RB275 275 230 176 140 103 70 20
RB300 320 270 211 172 135 90 30
RB350* 327 302 260 230 207 176 139 101 57
RB400 510 470 393 315 268 218 165 79 38
RB500 500 460 384 319 259 197 136 102 48
Power Consumption @ 120 VAC , 60Hz (2.0 Amp Maximum)
RB110 14 - 19 watts
RB275 50 - 75 watts
RB300 66 - 87 watts
RB350* 86 - 140 watts
RB400 95 - 152 watts
RB500 99 - 152 watts
Size:
*RB350 Not Energy Star Listed
Mounting: Mounting bracket included.
Recommended ducting: 4”, 6”, 8” or 10” Flexible Ducting.
Storage temperature range: 32 - 100 degrees F.
Normal operating temperature range: -20 - 120 degrees F.
Maximum inlet air temperature: 140 degrees F continuous.
Continuous Duty 3000 RPM
Thermally protected Class F Insulation
Rated for Indoor use only
Rated for Residential and Commercial use
Suitable for use with solid-state speed controls
Suitable for use over tub or shower
Fan Model “A” Dim “B” Dim “C” Dim Duct Size Weight
RB110 9.7” 3.9” 8.5” 4” 5 lbs
RB275 11.8” 5.9” 8.6” 6” 5.5 lbs
RB300 13.4” 5.9” 9” 6” 8 lbs
RB350* 13.4” 5.9” 9” 6” 8.5 lbs
RB400 13.4” 7.9” 10.5” 8” 11.5 lbs
RB500 13.4” 9.9” 10.5” 10” 11.5 lbs
77728
L
I
S
T
E
D
L
I
S
T
E
D
C
NOTE: RB350 IS NOT
HVI CERTIFIED
