With a Phillips screwdriver, remove the 28 packaging screws from all four sides of the crate.
Lift off the top of the crate and remove any boxes and accessories.
Lift the sides of the crate up and off the base and remove the tool kit.
With the 14mm open-ended wrench, remove all four bolts that secure the instrument to the bottom of the crate.
Remove the transit blocks by pushing in, then pull down and out.
1
2
3
4
5
4
1
2
3
5
