© SPX FLOW, Inc.
Form No. 1000623
Rev. 6 Jan. 10, 2017
TWHC1/3 Torque Wrench Parts List
Item No.
Part No.
Qty Description
TWHC1 TWHC3
1 TWHCAS010003 TWHCAS030003 1 TWHC Body Assembly
1.1 TWHCBD010001 TWHCBD030001 1 -TWHC Body
1.2 TWHCSJ010001 TWHCSJ030001 2 -TWHC Sideplate Journal
1.3 TWHCBB010001 TWHCBB030001 1 -TWHC Body Bush
2 TWHCAS010008 TWHCAS010008 1 TWHC Multiswivel Manifold Assembly
2.1 TWHCSP010001 TWHCSP010001 1 -TWHC Swivel Post
2.2 TWHCSB010001 TWHCSB010001 1 -TWHC Swivel Banjo
2.3 TWHCAY010001 TWHCAY010001 1 -TWHC Swivel Advance Yoke
2.4 TWHCAS010009 TWHCAS010009 1 -TWHC Swivel Retract Yoke
2.5
Multiswivel seal
Kit
TWHCAS010010
Multiswivel seal
Kit
TWHCAS010010
2 -Seal
2.6 1 -Seal
2.7 2 -Seal
2.8 2 -Seal
2.9 2 -Seal
2.10 STDHC000005 STDHC000005 1 -Female Coupling
2.11 STDHC000004 STDHC000004 1 -Male Coupling
2.12 INTHC000002 INTHC000002 1 -Adapter
2.13 STDRC000057 STDRC000057 1 -Clip
2.14 STDFA000025 STDFA000025 4 -Screw
2.15 STDFA000027 STDFA000027 1 -Screw
2.16 STDST000078 STDST000078 1 -Cap
3 TWHCAS010005 TWHCAS030005 1 TWHC Drive Assembly
3.1 TWHCCR010001 TWHCCR030001 1 -Crank
3.2 TWHCCB010001 TWHCCB030001 2 -Crank Bearing
3.3 TWHCRT010001 TWHCRT030001 1 -Ratchet
3.4 TWHCDS010001 TWHCDS030001 1 -Drive Shoe
3.5 STDST000105 STDST000106 2 -Spring
4 TWHCAS010004 TWHCAS030004 1 TWHC Piston Assembly
4.1 TWHCPI010001 TWHCPI030001 1 -Piston
4.2 TWHCPR010001 TWHCPR030001 1 -Piston Rod
4.3 STDRC000061 STDRC000062 1 -Clip
5
Body Seal Kit
TWHCAS010007
Body Seal Kit
TWHCAS030007
1 Seal
5.1 1 Seal
5.2 1 Seal
5.3 2 Seal
6 TWHCEC010001 TWHCEC030001 1 TWHC Endcap
7 TWHCBP010001 TWHCBP030001 2 TWHC Body Plug
8 BSDAS010008 BSDAS010008 2 TWHC Lock Button Assembly
