SPX FLOW TWHC Series - Parts Lists Continued; TWHC50 Torque Wrench Parts List (Continued)

© SPX FLOW, Inc.
Form No. 1000623
Rev. 6 Jan. 10, 2017
Parts Lists continued
Item No.
Part No.
Qty Description
TWHC50
1 TWHCAS500003 1 TWHC Body Assembly
1.1 TWHCBD500001 1 -TWHC Body
1.2 TWHCSJ500001 2 -TWHC Sideplate Journal
1.3 TWHCBB500001 1 -TWHC Body Bush
1.4 STDSE000097 1 -Seal
2 TWHCAS020001 1 TWHC Multiswivel Manifold Assembly
2.1 TWHCSP020001 1 -TWHC Swivel Post
2.2 TWHCSB020001 1 -TWHC Swivel Banjo
2.3 TWHCAY020001 1 -TWHC Swivel Advance Yoke
2.4 TWHCAS020002 1 -TWHC Swivel Retract Yoke
2.5
Multiswivel seal
Kit
TWHCAS020003
2 -Seal
2.6 3 -Seal
2.7 2 -Seal
2.8 2 -Seal
2.9 1 -Seal
2.10 STDHC000005 1 -Female Coupling
2.11 STDHC000004 1 -Male Coupling
2.12 INTHC000002 1 -Adapter
2.13 STDRC000064 1 -Clip
2.14 STDFA000157 4 -Screw
2.15 STDFA000027 1 -Screw
2.16 STDST000078 1 -Cap
3 TWHCAS500005 1 TWHC Drive Assembly
3.1 TWHCCR500001 1 -Crank
3.2 TWHCCB500001 2 -Crank Bearing
3.3 TWHCRT500001 1 -Ratchet
3.4 TWHCDS500001 1 -Drive Shoe
3.5 STDST000118 2 -Spring
4 TWHCAS500004 1 TWHC Piston Assembly
4.1 TWHCPI500001 1 -Piston
4.2 TWHCPR500001 1 -Piston Rod
4.3 TWHCPC500001 1 -Piston Rod Collar
4.4 STDRC000069 1 -Clip
5
Body Seal Kit
TWHCAS500007
1 Seal
5.1 1 Seal
5.2 1 Seal
5.3 2 Seal
6 TWHCEC500001 1 TWHC Endcap
