SPX FLOW W65 - Page 57

Waukesha Cherry-Burrell Brand W60/W80 Valves Parts Lists
08/2018 95-03022 Page 57
W64/W84 Tank Outlet Valve
Item # 1" & 1-1/2" 2" 2-1/2" 3" 4" Notes
Control Top
1 Actuator
* 2 Bearing
3 Adapter, W60 (Std.) 102407+ 102408+ 102409+ 102410+
3a W60 109294+ 109295+
W80 116926+ 116927+
3b Adapter, W80 106292+ 106293+ 106294+ 106295+ 2
3d Adapter, Wiping Stem Seal 117880+ 117881+ 117882+ 117883+ 1
* 4 O-ring EPDM
FKM
* 4a Wiping Stem Seal EPDM
FKM
5 Clamp Standard 119-33 119-34 119-51 119-87
High Pressure 119-272 119-273 3
* 6 O-ring, Body EPDM E70228 E70232 E70236 E70244
FKM V70228 V70232 V70236 V70244
7 Stem (less seat ring)
Tef-Flow
TM
102419+ 102420+ 102421+ 102422+
Tef-Flow
TM
Long Stroke
N/A 110967+ 110968+ 110969+
Tri Ring
108144+ 108145+ 108146+ 108147+
Tri Ring, Long Stroke
N/A 110986+ 110987+ 110988+
Metal
106400+ 106401+ 106402+ 106403+
Metal, Long Stroke
N/A 111001+ 111002+ 111003+
* 8 Seat Ring
Tef-Flow
TM
20-241 20-242 20-243 20-244
Tef-Flow
TM
P
115348+ 115349+ 115350+ 115351+
Tri Ring, EPDM 107695+ 107048+ 102488+ 107698+
Tri Ring, FKM 107986+ 107982+ 107974+ 107989+
10 High Pressure Backup Ring
12 Tank Flange 1/8" Thick 114825+ 114826+ 114827+ 114828+
1/4" Thick 114830+ 114831+ 114832+ 114833+
PL5027-CH5
114824+
114829+
BURT210
N/A
N/A
N/A
N/A
E70210
119-271
107692+
107983+
116925+
106291+
E70223
V70223
20-240
115347+
115626+
1
Adapter, High
Pressure
Contact Factory
See actuator parts list
108143+
N/A
106399+
N/A
Part Description
102757+
102406+
109293+
102418+
N/A
117879+
119-30
V70210
116183+
Notes:
* Recommended Spare Parts
1. Wiping Stem Seal Adapter and Wiping Stem Seal options available for W60 Series valves only.
2. W80 Adapter allows for liquid or steam flu
sh of stem o-ring only.
3. High Pressure Body Clamp only required for valves equipped with High Pressure Adapter (item 3a).
