iv
Battery Charger and Analyzer User Guide
WARNING:
• The battery charger and analyzer is intended only to test and charge 12V gel-cell, Absorbed Glass Mat (AGM),
and wet cell, lead-acid automotive rechargeable batteries. Other types of batteries may burst and cause per-
sonal injury.
• Do not operate the battery charger and analyzer where flammable liquids or vapors may be present. Sparks and
electrical arcing can occur during the test procedure.
• When plugging the power cord into an electrical outlet, avoid wet floors to prevent electrical shock.
• Unplug the battery charger and analyzer from an electrical outlet before performing maintenance. Turning off
the battery charger and analyzer does not reduce the risk of electrical shock.
• Do not alter the AC cord or plug provided. Do not use an adapter to fit a two-pole receptacle. This battery
charger and analyzer is equipped with an electrical cord having an equipment grounding conductor and a
grounding plug. The plug must be plugged into an outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
• Do not spray excessive liquids on the battery charger and analyzer case, they may enter the case and cause
permanent damage to the electrical components. Flammable liquids may cause an explosion.
• Remove metal jewelry such as rings, watches and bracelets. Contact with a battery post and ground can cause
severe burns or a spark that may cause an explosion.
• Do not operate the battery charger and analyzer if the power cord is damaged. Replace it immediately.
•Wear ANSI approved eye protection when testing or working with batteries.
• During a battery test, stand a safe distance away and place a shield around the battery to prevent direct
exposure to sulfuric acid.
• Do not remove the leads from a battery during the test. If a lead must be removed, press the “Clear” button to
stop the test.
Important:
• Do not use an extension cord to connect the battery charger and analyzer.
• Do not cut the grounding prong off the AC power cord.
• When removing the power cord from an electrical outlet, pull out by the plug to reduce damage to the power
cord.
• The battery must be removed from the vehicle before testing. Damage to the vehicle computer system may
occur if the battery is tested in the vehicle.
• Before removing the battery from the vehicle, turn Off the ignition, accessories and any other battery load.
Remove the Negative (-) battery cable first, then remove the Positive (+) battery cable. Install the battery in the
reverse order.
Specifications
• Battery Test Range: 12 volt automotive battery rated at 150-1500 Cold Cranking Amps (CCA), 200-1900 Cranking Amps
(CA, MCA).
• Amphere Hours: 26-260
• Operating Temperature Range: 0°C to 50°C / 32°F to 122°F
• Storage Temperature Range: -20°C to 70°C / 4°F to 158°F
• Humidity Range: 0 to 85%
• Power Supply Parameters: Input volts must be 120 VAC, Input amps must be 20 A . A dedicated line is required. Failure
to adhere to the power requirements can cause inaccurate test results or a break in the electrical circuit.
• Installation Requirements: Non-portable; indoor use only; 120 VAC, 60 Hz, 20 A.
• Current Draw: 16 Amps, not including 120v. printer accessory outlet.
• Commercial Charger: Intended for use on automotive batteries, not intended for use in household or industrial applications.
