SPX 5012A - Page 5

© SPX Corporation
Parts List & Operating Instructions Form No. 106218
Description
Item
No.
Part
No.
No.
Req'd
1 j 1 Seal
(2-5/8 x 2-7/8 x 1/18; loaded lip)
2 5012-02 2 Plug (1/8 NPT)
3 5012-03 1 Jack Cap
4 j 2 Backup Ring (3-1/8 x 3/16 x 3-1/2)
5 5012-05 1 Extension Screw
6 5012-86 1 Hydraulic Ram
7 5012-07 1 Hydraulic Cylinder
8 5012-08 1 Outer Barrel Weldment
9 5012-09 1 Bladder
11 j 1 Quad Ring
(2-3/4 x 1/8 x 3)
12 5012-87 1 Socket Hd. Cap Screw (6-32 UNC x 1/4" lg.)
13 j 1 Seal (2-1/2 x 3 x 1/4)
14 5012-88 1 Base Plate
15 j 2 Quad Ring (7/16 x 1/4 x 3/32)
16 j 1 Backup Ring (11/16 x 1/2)
18 5012-89 1 Pump Housing
19 5012-19 1 Pump Plunger
20 j 1 Seal
(9/16 x 5/16 x 1/8)
21 5012-97 1 Pump Housing Cap
22 j 2 Quad Ring (3 x 2-5/8 x 3/16)
23 5012-23 1 Compression Spring (1-3/4 OD)
24 5012-93 1 Retaining Ring
25 j 1 O-ring
(2-1/4 x 1/16 x 2-1/8)
26 5012-91 1 Motor Housing
27 j 1 Shuttle Valve Seal (31/32 dia.)
28 j 1 Seal (1-1/4 x 1 x 1/8)
29 5012-94 1 Air Shuttle Piston
30 5012-92 1 Piston Cap
31 5012-31 1 Compression Spring
(1/4 ID x 3/8" lg.)
32 5012-32 1 Ball (3/8 dia.)
33 5012-33 1 Check Valve Spacer
34 5012-34 1 Male Elbow
(90 ° x 1/8 NPTF)
35 5012-35 1 Plug
36 5012-36 2 Ball (1/4 dia.)
37 5012-37 1 Plastic Plug
38 5012-38 1 Plug (SAE #4)
39 5012-39 1 Male Connector (1/8 NPTF)
41 j 1 O-ring (3/8 x 1/4 x 1/16)
42 5012-42 1 Release Stem
43 5012-43 1 Roll Pin (3/16 dia. x 3/4" lg.)
45 5012-45 1 Flex Shaft
j Items marked with an asterisk are
included in Seal Kit No. 222954.
Sheet No. 3 of 4
Issue Date: Rev. C, 8-16-02
