7. Ensure shoulder rest handles are positioned to the outside of
the shoulder rest frames.
8. Place 1/4" black washers over the shoulder rests screw
holeslots.
9. Insert 1/4" x 1-1/4" screws through washers and into top of
screw holes.
10. Use the 1/8" Allen key provided to tighten, ensuring the
shoulder rests are secure.
11. To determine correct length of ropes, set carriage stopper in
second hole from footbar. Engage a spring [6] into the gearbar [5]
ensuring carriage [16] does not move.
12. Place double loop straps [19] on carriage so D-rings on straps
line up with back of metal plate of shoulder rests.
Subtle adjustments can be made to length of ropes by sliding
rope guide tubes [27]. Secure by tightening star knobs [21].
