Read Before Using
SPEED - ACCURACY - FREEDOM FROM STRIPES AND STREAKS
are yours - when you use this Spreader.
The spread width ranges from 4 ft. to 12 ft. wide, depending on the
volume/density, particle size of the material and the rate of travel.
The spread thins or feathers at the outer edges, eliminating sharp,
“Edge of spread” lines which cause stripes and streaks. Extra coverage
can be given under trees and other heavy feeding areas without
showing “edge of spread” lines.
Gaps and double overlaps are less likely. Small errors in travel are
forgiven and do not show.
WARNING: When spreading products containing herbicides, exercise extreme
caution with respect to careless spreading and to wind-drift.
CONTACT OF SOME PRODUCTS ON SOME PLANTS CAN BE FATAL.
If a dial setting is not found, use the size and weight comparison table
found on the back page.
Determine a dial setting on the low side. If the setting proves to be
too low, cover the area more than one time. A higher setting can be
used when a proven dial setting is established.
REMEMBER - Published dial settings can be approximate only. The
operation of the spreader, the condition of the material (damp or dry
or over-pulverized) and weather conditions, are all contributing factors.
For these reasons, it’s often a good idea to spread the area 2 times -
at one-half rate - in cross directions (SEE INFORMATION ON ONE-HALF
RATE DIAL SETTINGS ON REFERENCE CHART ON THE BACK PAGE.
SPREADING AT ONE-HALF RATE DIAL SETTINGS IS HIGHLY
RECOMMENDED UNDER DAMP & HUMID CONDITIONS.
BECOME FAMILIAR WITH THE OPERATION OF THE SPREADER
BEFORE YOU PUT MATERIAL IN THE HOPPER.
Practice walking with the spreader, opening and closing the rate gate
at the appropriate times.
Travel at a constant speed and operate the spreader lever position.
Remember: Open the rate gate after the spreader is in motion at
operating speed (about 3 mph.).
Close the rate gate while spreader is still at operational speed.
76
Model 80 Parts List
Item # Part # Quantity Description
1 05-98-0104 1 On/Off Control Lever
2 05-95-0046 2 Idle / Drive Wheel
3 05-94-0042 2 Rate Gate Guide
4 05-94-0064 4 Nylon Washer / Hopper
5 SS-94-0007 1 Hopper Bottom Bearing
6 05-94-0043 1 AccuwayTM
7 SS-94-0011 2 Axle Bushing
8 SS-96-0003 1 Agitator Wire
9 99-10-0205 5 Bolt 1/4-20 x 1/2” / Hopper Bottom Plate
10 05-90-0098 2 Jay Bolt / Handle
11 05-98-0089 2 Plastic Knob / Handle / Jay Bolt
12 05-94-0103 2 Plastic Plug / Hopper Support Tube End
13 05-90-0054 8 Bolt 1/4-20 x 1 1/2” / Hopper / Frame Braces
14 SS-91-0004 10 Lock Nut 1/4-20 / Hopper / Frame / Frame Braces
15 05-90-0038 2 Bolt 1/4-20 x 2” / Frame
16 05-90-0042 2 Bolt 10-24 x 1 1/4” / On/Off Lever
17 05-91-0008 2 Lock Nut 10-24 / On/Off Lever
18 05-90-0065 1 Clevis Pin 3/16” x 1 3/4” / Drive Wheel
19 05-90-0089 1 Hair Pin / Drive Pin
20 05-90-0055 1 Bolt 10-32 x 1/2” SS HH / Cable Retainer
21 SS-92-0002 2 Felt Washer / Gear Box / Hopper
22 05-94-0102 1 Handle Grip
23 05-98-0120 2 Collar 1/2” / Axle
24 05-80-2202 2 Axle Support Tube
25 05-71-2205 1 Hopper Bottom Plate
26 05-88-2241 1 Cable Retainer / Cable Mount Bracket
27 05-35-2203 1 Ground Prop / Hopper Support
28 SS-90-0001 2 Roll Pin, .125 x 3/4” / Bevel Gear / Pinion Gear
29 SS-90-0002 2 Roll Pin, 1/8” x 7/8” / Bevel Gear / Pinion Gear
30 SS-94-0010 1 Bevel Gear
31 SS-94-0009 1 Pinion Gear
32 SS-94-0012 1 Spinner
33 05-94-0029 1 Bushing / Gear Box
34 SS-94-0014 4 Clamp Ring / Gear Box
35 SS-94-0008 2 Gear Box Half
36 05-35-0060 1 Spinner Shaft
37 05-35-0050 1 Axle
38 05-80-0030 1 Hopper
39 05-94-0068 1 Rate Gate
40
05-94-0069 1 Dial Mount
41 SS-94-0006 1 Dial
42 05-90-0044 1 Cable / Wire Fastener
43 05-94-0078 1 Pine Tree Clip / Dial Mount
44 05-24-1102 1 Rate Gate Linkage
45 05-35-2204 1 Handle
46 05-94-0045 1 AccuwayTM Adjustment Screw
47 05-94-0046 1 AccuwayTM Nut / Bracket
48 05-35-0280 1 Cable Mount Bracket
49 05-35-1040
2
Frame Brace
