6
Components
1 Photo lens Image sensor and infrared lter.
2 Invisible LEDs Night lighting to obtain black and white
photos and videos.
3 Test light Flashes in TEST mode when there is detec-
tion and ashes 60 seconds in PHOTO/VIDEO
mode to allow the user to leave without being
photographed or recorded.
4 Light sensor Allows the lighting of the LEDs panel at night.
5 Fresnel lens Expands the detection area and increases the
sensitivity of the camera’s motion sensor.
6 Slot for installation
strap
Allows the user to install the camera using
the installation strap included (p.10).
7 Cable lock hole Allows the user to install a CL-6FT cable lock,
sold separately (p.20).
8 12V power jack This camera can be powered from an external
12-volt DC input such as a 12V battery or a
12V adapter, each sold separately (p.19).
9 Tripod mount Standard ¼-20" tripod mount.
10 Microphone Record sound in video mode (p.15).
11 Solar panel jack Allows the user to connect a solar panel
(SP-12V) to maintain the charge of the
lithium battery pack (LIT-09/LIT-C-8), sold
separately (p.19).
12 Access to the time
battery
Battery that keeps the time and date in
memory (p.8).
13 Battery switch Allows the user to select the power source ac-
cording to the type of batteries used (p.7).
14 BUSY LED Lights up when the camera is recording
(p.9).
15 ON/OFF Allows the user to turn on/off the camera.
16 Built-in speaker
(BF-12
HD
)
When viewing videos, allows to hear the
sound.
17 Viewing screen Allows the user to access the main menu and
view photos/videos. Screen with zoom and
pan functions (p.10).
18 Navigation buttons Buttons to set the camera (p.10).
19 Battery case Case for AA batteries or a rechargeable
lithium battery pack (p.7).
20 TV OUT Allows the user to view or delete photos/
videos directly on TV (p.13).
21 USB port To transfer photos/videos to a computer
(p.16).
22 SD card slot An SD card is required to record photos/videos
(p.9).
23 DISTANCE dial Allows the user to adjust the distance of
detection and the sensitivity of the detector
(p.13).
