CONNECTING TO A CAMERA
KIT-12V
Connect the power cable (included) from the "to camera" plug
to the "12V" outlet of the camera. (see figure below, section
"Connecting to solar panel")
BATT-12V
To connect the battery to the camera with a power cable (CB-
12FT sold separately), connect the "alligator" clips from the
cable to the battery. Exact polarity must be followed (red =
+
, black =
-
). Connect the other end to the camera (see image
below).
RED
BLACK
RED
BLACK
SPYPOINT camera
12V battery
CB-12FT cable
