© 2013–2017 Schneider Electric Reservados todos los derechos
80043-808-02 Rev. 02 Tableros de distribución combinados I-Line™
03/2017 Anexo 1: Especificaciones—Corriente nominal de cortocircuito adicional
39
ESPAÑOL
208Y/120
3P/4W
65,000
LJ
QO (B) 15–70 A 15–125 A
QO (B) VH 15–70 A 15–125 A 15–150 A
QO (B) H 15–100 A
QO (B) GFI 15–30 A 15–60 A 15–30 A
QO (B) EPD 15–30 A 15–60 A 15–30 A
QO (B) EPE 15–30 A
QO (B) AFI 15–20 A
QO (B) CAFI 15–20 A
QO (B) DF 15–20 A
LL
QO (B) GFI 15–30 A
QO (B) EPD 15–30 A
QO (B) EPE 15–30 A
100,000
DJ 400 A
QO (B) 15–70 A 15–125 A
QO (B) VH 15–150 A
QO (B) GFI 15–30 A 15–60 A
QO (B) EPD 15–30 A 15–60 A
QO (B) AFI 15–20 A
QO (B) CAFI 15–20 A
QO (B) DF 15–20 A
QJ
QO (B) 15–70 A 15–125 A 15–30 A
QO (B) VH 15–150 A
QO (B) PL 15–30 A 15–60 A 15–30 A
QO (B) GFI 15–30 A 15–60 A 15–50 A
QO (B) EPD 15–30 A 15–60 A 15–50 A
QO (B) EPE 15–30 A 15–60 A 15–50 A
QO (B) AFI 15–20 A
QO (B) CAFI 15–20 A
QO (B) DF 15–20 A
Continued on next page
Table 8: Series Connected Breaker Ratings (RMS Symmetrical) (continuación)
Max.
System
Voltage
AC
1, 2
Max.
Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers
and Remote
Main Fuses
Square D Brand Branch Circuit Breaker
Catalog Designation and Allowable
Ampere Ranges
3, 4, 5, 6
Type 1 Pole 2 Pole 3 Pole
