Square D I-Line User Manual

© 2013–2017 Schneider Electric All Rights Reserved
I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Specifications—Lighting Section Ratings 03/2017
36
ENGLISH
Table 8: Series Connected Breaker Ratings (RMS Symmetrical)
Max.
System
Voltage
AC
1, 2
Max.
Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers
and Remote
Main Fuses
Square D Brand Branch Circuit Breaker
Catalog Designation and Allowable
Ampere Ranges
3, 4, 5, 6
Type 1 Pole 2 Pole 3 Pole
120/240
7
1P/3W
22,000 MG QO (B) 15–30 A — —
25,000 LD, HD, JD
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
65,000
HG, JG
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
LG
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
LJ
QO (B) GFI 15–30 A 40–60 A —
QO (B) EPD 15–30 A 40–60 A —
100,000 HJ, JJ
QO (B) 15–70 A 15–125 A —
QO (B) VH 15–70 A 15–125 A —
QO (B) PL 15–30 A 15–60 A —
QO (B) GFI 15–30 A 15–60 A —
QO (B) EPD 15–30 A 15–60 A —
QO (B) AFI 15–20 A — —
QO (B) CAFI 15–20 A 15–20 A —
QO (B) DF 15–20 A — —
80043-808-01.book Page 36 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
