80043-808-02 Rev. 02 I-Line™ Combo Switchboards
03/2017 Specifications—Lighting Section Ratings
35
ENGLISH
600Y/347
18,000
HG, JG, MG EDB
LG EDB (15–110 A)
25,000
EJ, FI, KH, KI, LC, LE, LX, LI, LXI, HJ, JJ EDB, EGB
LJ EDB (15–110 A), EGB (15–110 A)
LH EDB (15–70 A), EGB
35,000 LC, LE, LX EDB, EGB, EJB
50,000
HL, JL EDB, EGB, EJB
LL
EDB (15–110 A), EGB (15–110 A),
EJB (15–110 A)
65,000
FI, KI, HR, JR EDB, EGB, EJB
LI, LXI, LR EJB
200,000 Class J or T (600 V) 200 A Max Fuses EDB, EGB, EJB
1
Short circuit tests are conducted at 100–105% of the maximum rated voltage of the I-Line Combo switchboard.
Table 7: NF Series Connected Circuit Breaker Ratings
(RMS Symmetrical) (continued)
Max.
System
Voltage
AC
1
Max. Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers and
Remote Main Fuses
Square D Brand
Branch Circuit Breaker Catalog
Designation and Allowable
Ampere Ranges
80043-808-01.book Page 35 Wednesday, March 22, 2017 12:31 PM
