I-Line™ Combo Switchboards 80043-808-02 Rev. 02
Specifications—Lighting Section Ratings 03/2017
34
ENGLISH
Table 7: NF Series Connected Circuit Breaker Ratings
(RMS Symmetrical)
Max.
System
Voltage
AC
1
Max. Short
Circuit
Current
Rating
Square D Brand
Integral or Remote
Main Circuit Breakers and
Remote Main Fuses
Square D Brand
Branch Circuit Breaker Catalog
Designation and Allowable
Ampere Ranges
120
120/240
240
65,000
EG, FH, FG, KH, LH, MH, MX, HG, JG,
DG
EDB, EDB-EPD
LG EDB
EG ECB-G3
100,000
EJ, FC, FJ, KC, LC, HJ, JJ EDB, EDB-EPD, EGB
DJ, LJ EDB, EGB
EJ, FC, KC, HJ, JJ ECB-G3
125,000 HL, JL EDB, EDB-EPD, EGB, ECB-G3
200,000
HR, JR EDB, EGB, EJB
LR EGB-EPD, EJB-EPD
FI, KI, LI, LXI, LR EDB, EDB-EPD, EGB, EJB
FI, KI, HR, JR ECB-G3
Class J or T (600 V) 200 A Max Fuses ECB-G3
277
480Y/277
35,000
EG. FG, KH, LH, HG, JG, DG, LG EDB, EDB-EPD
EG, HG, JG ECB-G3
65,000
EJ, FC, FJ, KC, LC, LX, HJ, JJ, DJ EDB, EDB-EPD, EGB
EJ, FC, KC, HJ, JJ ECB-G3
LJ EDB, EDB-EPD, EGB, EGB-EPD
LL EDB-EPD, EGB-EPD
100,000
HL, JL EDB, EDB-EPD, EGB, EJB
DL, LL EDB, EGB, EJB
400 A Max Fuses EDB, EDB-EPD, EGB, EJB
200,000
HR, JR, LR EGB-EPD, EJB-EPD
FI, KI, LI, LXI, HR, JR, LR EDB, EDB-EPD, EGB, EJB
FI, KI, HR, JR ECB-G3
200 A Max Fuses EDB, EDB-EPD, EGB, EJB, ECB-G3
Continued on next page
80043-808-01.book Page 34 Wednesday, March 22, 2017 12:31 PM

Square D I-Line Specifications

General

Bus Material	Aluminum or Copper
Voltage Rating	600V AC
Current Rating	Up to 1200A
Enclosure	NEMA 1
Poles	2, 3
Interrupting Rating	200 kA (depending on the specific model and installed breakers)
