Srne ML2440 - 6 Conversion Efficiency Curve

Low Voltage Disconnect
Restoring Voltage
12.6V 12.6V 12.6V 9
～
17V
Under-Voltage Alarming
Restoring Voltage
12.2V 12.2V 12.2V 9
～
17V
Under-Voltage Alarming
Voltage
12.0V 12.0V 12.0V 9
～
17V
Low Voltage Disconnect
Voltage
11.1V 11.1V 11.1V 9
～
17V
Discharging Limit Voltage 10.6V 10.6V 10.6V 9
～
17V
Over-Discharge Delay Time 5s 5s 5s 1
～
30s
Equalizing Duration Time 120 minutes —— 120 minutes 0
～
600 minutes
Equalizing Charging
Interval
30 days 0 day 30 days 0
～
250D
（
00
refers to close
equalizing
charging
function
））
Boost Duration Time 120 minutes 120 minutes 120 minutes 10
～
600 minutes
The User battery is customized battery. The system’s default voltage parameters are
consistent with sealed lead-acid battery parameters. When modifying battery charging and
discharging parameters, observe the following logic:
Overvoltage Disconnect Voltage
＞
Charging Limit Voltage≥ Equalizing Voltage≥ Boost
Voltage≥ Floating Charging Voltage
＞
Boost Restoring Voltage
；
 Overvoltage Disconnect Voltage
＞
Overvoltage Disconnect Restoring Voltage
；
 Low Voltage Disconnect Restoring Voltage
＞
Low Voltage Disconnect Voltage≥
Discharging Limit Voltage
；
 Under-Voltage Alarming Restoring Voltage
＞
Under-Voltage Alarming Voltage≥
Discharging Limit Voltage
；
 Boost Restoring Voltage
＞
Low Voltage Disconnect Restoring Voltage
；
6. Conversion Efficiency Curve
6.1.12V System Conversion Efficiency
