BREW DAY OPERATIONS (CONTINUED)
2V OPTIONS
The 2V eController includes two PID controllers as well as an element selection switch. The two PID
controllers are labeled as “HLT/MASH” and “BOIL KETTLE” on the face of the eController. The element
selector switch’s function is to switch the power output to either the “HLT/MASH” element or “BOIL
KETTLE” element.
Due to voltage and amperage requirements, only one element can be activated at a time on a 208VAC
to 240VAC circuit.
The procedure to adjust temperature and percentage on the eController 2V is identical to the eController
1V. The 2V does, however, include an element selector switch that allows you to select which element
you want to activate. When using the eController 2V, be sure to pay close attention to which element
you activate so that you do not accidentally dry re an element that may not be completely submerged.
Once the selector switch is in the desired position, the element can be turned on by depressing the
“HEATER ON” button. To deactivate power, simply press and release the button once more.
Only the boil kettle portion of the 2V controller has voltage modulation to ne tune the element wattage
output via the “MAN” or “AUTO” switch setup. This rocker switch is located above the controller read out
marked “BOIL KETTLE”. The “HLT/MASH” controller only supports an auto PID tuning setting based
on a set point since this is used to maintain to maintain a specic temperature for both a HLT and
mash tun.
Always verify the element is fully submerged in water before activating the heater element. Dry ring
the element will cause irreversible damage to the element coil and void the element’s warranty.
O
F
F
O
N
O
F
F
O
N
Element Selector Switch
