SSANGYONG Actyon 2008.01 User Manual

06-4
A
CTYON 2008.01
0000-00
ENGINE COOLING SYSTEM
1520-00
WATER PUMP
1. OVERVIEW
The belt-driven centrifugal water pump consists of an impeller, a drive shaft, and a belt pulley.
The impeller is supported by a completely sealed bearing. The water pump is serviced as an
assembly and, therefore, cannot be disassembled.
The capacity of water pump has been increased due to the EGR cooler, increased engine
power and additional coolant port in the cylinder block.
For D20DT (EURO4) engine For D20DT engine
Port to EGR cooler
