SSANGYONG Actyon 2010 User Manual

CIRCUIT
1461-01/2820-01/1491-01/8210-01/3110-01/3740-01/3410-01/4892-01/8810-01/8010-01/7410-13/7410-04/8510-52/8510-48/8710-02/7830-03/8510-05
/
8610-06/7632-16/7340-03/8310-01/8510-00/8320-01/8410-01/8210-01/8310-10/4810-01/7770-02/7770-10/8910-01/8790-01/6810-15/6910-01/6810-20
CIRCUIT
ENGINE
1461-01 STARTING ＆ CHARGING............
2820-01 PREHEATING CIRCUIT................
1491-01 ECU (ENGINE CONTROL
UNIT - D20DT EU-IV)....................
1491-01 ECU (ENGINE CONTROL
UNIT - D20DT)..............................
1491-01 ECU (ENGINE CONTROL
UNIT - GSL G23)..........................
8210-01 DIAGNOSIS CIRCUIT...................
CHASSIS
3110-01 TCU..............................................
3740-01 A/T SHIFT LOCK..........................
3410-01 TCCU...........................................
4892-01 ABS/ESP......................................
ELECTRIC
7770-10 AUTO DIMMING ROOM
MIRROR CIRCUIT........................
8910-01 AUDIO ＆ CLOCK CIRCUIT..........
8790-01 PARKING AID CIRCUIT................
6810-15 PTC HEATER
(POSITIVE TEMPERATURE
COEFFICIENT).............................
6910-01 FFH (FUEL FIRED HEATER).........
6810-20 FATC (FULL AUTO TEMP.
CONTROL) CIRCUIT....................
6810-20 AIR-CON (MANUAL) CIRCUIT.......
8810-01 AIR-BAG (CURTAIN AIR-BAG)......
8010-01 CLUSTER.....................................
7410-13 POWER SEAT - DRIVER..............
7410-04 POWER SEAT - PASSENGER.....
8510-52 ELECTRIC OUTSIDE MIRROR.....
8510-48 FRT SEAT WARMER...................
8710-02 STICS..........................................
7830-03 RR WIPER CIRCUIT.....................
8510-05 POWER WINDOW CIRCUIT..........
8610-06 HORN...........................................
7632-16 CIGAR LIGHTER ＆
POWER OUTLET CIRCUIT..........
7340-03 SUN ROOF CIRCUIT....................
8310-01 HEAD LAMP ＆ DRL
(DAY TIME RUNNING LIGHT)
UNIT CIRCUIT..............................
8510-00 HLLD
(HEAD LAMP LEVEL’G DEVICE)
CIRCUIT.......................................
8320-01 TAIL LAMP CIRCUIT....................
8410-01 TURN SIGNAL ＆
HAZARD LAMP CIRCUIT..............
8210-01 TRAILER LAMP CIRCUIT.............
8310-10 FOG LAMP CIRCUIT....................
4810-01 STOP & BACK-UP
LAMP CIRCUIT............................
7770-02 INTERIOR LAMP CIRCUIT...........
3
4
5
8
11
14
15
16
17
18
20
21
23
24
25
26
27
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
56
CIRCUIT
