01-11
ENGINE GENERAL
undefined
0000-00
Preheat Control Unit
NO. FUNCTION
1 Glow plug terminal (#1 ~ #4)
2
No G5 for 4 cylinders
(Without D20DT)
3 IG1 power supply terminal
4 Glow plug control signal (ECU113)
5 Ground terminal
6 Battery main wire
7
Preheat completion transmit
terminal : No use for vehicle
without remote engine start
8 K-line (ECU 34)
