11-3
8910-05
1. SPECIFICATION
1) Audio Head Unit
Item Specification
A
udio Voltage DC 14.4V
Operating voltage DC 10.8V~16.0V
Output 45W/1ch 4ch
Current consumption 5 A or less Up to 10 A
Leakage current 3 mA or less
Radio Frequency FM: 87.5~108MHz
AM: 531~1602KHz
MW: 522~1620KHZ
LW: 144~290KHZ
Preset FM1: 6ch
FM2: 6ch
AM: 6ch
MW : 6ch
LW : 6ch
Usable sensitivity AM: 25dBu
FM: 10dBu
S/N raito (limit value) AM: 54dB
FM: 60dB
LCD Type FSTN
Operating voltage 9.0V VDD: 3.0~3.3V
Operating temperature -30℃ ~ +80℃
Operating temperature -40℃ ~ +85℃
Size (W x H) 132X36
Bluetooth Component MD-5XR (Bluetooth multimedia module)
A
pplication technolog
y
Bluetooth 2.0+EDR (Enhanced Data Rate)
Specification Supports HFP, A2DP, AVRCP profile formats
(HFP, A2DP: profile for calling)
(AVRCP: profile for listening music)
