Operations & Maintenance
Filter Info and Maintenance
SST00304
008
During all maintenance procedures, air input should be
physically disconnected to prevent injury or damage.
IMPORTANT
Stage 1 — Sintered Filter
Removes 95% of the moisture, oil, and debris particles up to 5 micron.
REPLACE WHEN: With air input applied, the MEGAFLOW Filter
indicator shows RED.
• The element should be replaced every 6 months to 1 year,
depending on the use levels.
REPLACEMENT PROCEDURE:
1. Ensure air input has been disconnected from the unit
2. Remove the 1st stage Filter Canister Housing by unscrewing it from the MEGAFLOW
Manifold Body
3. Unscrew the Sintered Filter Flow Nut to allow the used Brass Sintered Filter Element
to fall
4. Place the new Brass Sintered Filter Element on top of the Sintered Filter Flow Nut,
with the O-ring in between, and screw onto the threaded post
a. DO NOT OVERTIGHTEN
5. Visually confirm that the filter is experiencing no misalignment
6. Install the replacement coalescing filter
a. DO NOT OVERTIGHTEN
7. Re-install the Filter Canister Housing
a. Ensure O-Ring is properly seated in the top lip groove
b. Hand Tighten Only
WWW.STUPIDSIMPLE.TOOLSSST003
