Stage 2 — Coalescing Filter
Removes 99.99% of the moisture, moisture vapor and oil particles up to
0.01 micron
REPLACE WHEN: Filter status indicator shows RED with input air
applied
• The element should be replaced every 6 months to 1 year,
depending on the use levels.
REPLACEMENT PROCEDURE:
1. Ensure air input has been disconnected from the unit
2. Remove the 2nd stage Filter Canister Housing by unscrewing it from
the MEGAFLOW Manifold Body
3. Remove the used coalescing filter by unscrewing it
4. Install the replacement coalescing filter
a. DO NOT OVERTIGHTEN
5. Re-install the Filter Canister Housing
a. Ensure O-Ring is properly seated in the top lip groove
b. Hand Tighten Only
Operations & Maintenance
Filter Info and Maintenance
