ST7735R
V0.2 131 2009-08-05
Register
Availability
Status Availability
Normal Mode On, Idle Mode Off, Sleep Out Yes
Normal Mode On, Idle Mode On, Sleep Out Yes
Partial Mode On, Idle Mode Off, Sleep Out Yes
Partial Mode On, Idle Mode On, Sleep Out Yes
Sleep In Yes
Default
Status Default Value
C0h
Power On Sequence 82h/02h/84h
S/W Reset 82h/02h/84h
H/W Reset 82h/02h/84h
Flow Chart
