11
REPAIR PARTS LIST – “JB” SERIES - HIGH HEAD
MOTOR AND HORSEPOWER
JBHB-61S JBHC-61S JBHD-62S JBHE-63S JBHF-51S JBHG-52S JBHHG-53S
Key Part No. – JBHC3-61S JBHD3-62S JBHE3-63S JBHF3-51S JBHG3-52S JBHHG3-53S
No. Description Used 1/3 HP 1/2 HP 3/4 HP 1 HP 1-1/2 HP 2HP 2-1/2 HP
1 Motor, 115/230V, 1 Phase 1 J218-582APKG J218-582APKG J218-590PKG J218-596PKG J218-601PKG J218-883APKG J218-628APKG
1 Motor, , 230/460V, 3 Phase 1 – AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
†2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 C3-1042P C3-1042P C3-1042P C3-1042P C3-1042P C3-181 C3-181
†4 Gasket, Seal Plate 1 C20-121 C20-121 C20-121 C20-121 C20-121 C20-122 C20-122
†5 Shaft Seal 1 U109-6A U109-6A U109-6A U109-6A U109-6A U109-6A U109-6A
6 Impeller, Single Phase 1 C5-256BA C5-256BA C5-256BAA C5-254BA C5-254BC C5-257BB C5-257B
6 Impeller, Three Phase 1 – C5-256BA C5-256BAA C5-254BA C5-254BC C5-257BB C5-257B
6A Impeller Screw, Three Phase 1 C30-14SS C30-14SS C30-14SS C30-14SS C30-14SS C30-14SS C30-14SS
7 Volute Assembly with Wear Ring 1 C101-284A C101-284A C101-284A C101-284A C101-284A C101-264 C101-264B
7A Wear Ring 1 C23-27 C23-27 C23-27 C23-27 C23-27 C23-27 C23-27
8 Pipe Plug, 1/4” NPT Hex Hd. 3 U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV U78-941ZPV
9 Base with Motor Pad 1 J104-9 J104-9 J104-9 J104-9 J104-9 J104-9 J104-9F
9A Motor Pad 1 C35-5 C35-5 C35-5 C35-5 C35-5 C35-5 C35-5
10 Hex Capscrew, 3/8” - 16 x 1” Lg. 2 – – – – – U30-74ZP U30-74ZP
10 Socket Head Capscrew, 3/8” - 16 x 1” Lg.
(JBHHG-53S) 2 – – – – – – U30-99SS
10 Hex Capscrew, 3/8” - 16 x 1-1/4” Lg. 2 U30-75ZP U30-75ZP U30-75ZP U30-75ZP U30-75ZP – –
11 Hex Capscrew, 3/8” - 16 x 1-1/4” Lg. 2 U30-75ZP U30-75ZP U30-75ZP U30-75ZP U30-75ZP U30-75ZP U30-75ZP
11 Socket Head Capscrew, 3/8” - 16 x 1-1/4” Lg.
(JBHHG-53S) 2 – – – – – – U30-104ZP
* For repair or service to motors, always give the motor Model Number and any other data found on the Motor Model Plate.
