STA-RITE System 2 - Specifications

4
Dim B
Minimum
Service
Height
Dim A
18.58" Dia.
(472 mm)
15" Dia.
(381 mm)
2.25"
(57 mm)
Outlet
2" NPT
Drain
Plug
Lower
Tank
Shell
Safety
Latch
Posi-Lok™
Ring
Upper
Tank
Shell
Air Release Valve
(Pressure Gauge
Behind)
4310 0203
Inlet
or Drain
2" NPT
2" NPT
Inlet or
Drain
INLET
INLET
R
E
L
E
A
S
E
R
E
L
E
A
S
E
To Pool
From
Pool
Outlet
Inlet
Pump
Filter
4085 1001
SPECIFICATIONS
FIGURE 1A – Dimensions in inches (mm)
Table 1 - Filter Specifications
Model No.
PLM100 PLM125 PLM150 PLM175 PLM200 PLM300
Filter Area sq. ft. (m
2
) 100(9.3) 125(11.6) 150(14) 175(16.3) 200(18.6) 300(27.9)
Max. Rated Flow GPM (LPM)
Commercial 37(140) 47(178) 56(212) 66(249) 75(284) 113(428)
Max. Operating Pressure PSI (kPa) 50(345) 50(345) 50(345) 50(345) 50(345) 50(345)
Max. Continuous Water
Temperature F(C) 104°(40°) 104°(40°) 104°(40°) 104°(40°) 104°(40°) 104°(40°)
Dimension A – Height (mm) 27-3/4(705) 27-3/4(705) 27-3/4(705) 27-3/4(705) 27-3/4(705) 37-5/8(956)
Dimension B – Minimum Serivce
Height (mm) 38-1/2(978) 38-1/2(978) 38-1/2(978) 38-1/2(978) 38-1/2(978) 57(1,448)
FIGURE 1B – Piping Connections
4 (28)
2 (14)
6 (41)
8 (55)
10 (69)
12 (88)
14 (97)
16 (110)
18 (124)
Pressure Drop in Pounds per Square Inch (kPa)
10
(38)
20
(76)
40
(151)
60
(227)
80
(303)
100
(378)
120
(454)
140
(529)
160
(606)
Flow in Gallons Per Minute (LPM)
20 (138)
150
(568)
FIGURE 2 – Pressure Drop Curve
