11
Key No. Description Qty. Model S7S50 Model S8S70
1 2" Gauge 1 33600-0023T 33600-0023T
2 Valve Assembly 1 WC212-120P WC212-120P
3 Nipple 1 U37-16P U37-16P
4 Adapter Bushing 1 24900-0504 24900-0504
5 O-Ring 1 35505-1423 35505-1423
6 Tank - Upper Half Kit* 1 24851-9000 24851-9001
7 Collector - Manifold Assembly 1 24900-0100S 24901-0100S
8 Air Bleed Filter 1 WC8-126 WC8-126
9 Vent Tube 1 WC37-386P WC37-386P
10 Elbow - Male Parflex 1 WC78-84P WC78-84P
11 Lateral 16 24900-0002 24900-0003
12 O-Ring 2 35505-1424 35505-1424
13 Plug (Sand Removal) 1 24900-0503 24900-0503
14 Drain Fitting 1 24900-0505 24900-0505
15 1-1/2" NPT Plug 1 27001-0022S 27001-0022S
16 O-Ring 2 35505-1425 35505-1425
17 Tank Fitting 1 24900-0500 24900-0500
18 Tank Fitting 1 24900-0501 24900-0501
19 Clamp Assembly ** 24850-0200 24850-0200
19A Clamp Bolt ** 24850-0010 24850-0010
20 Tank - Lower Half 1 24850-0102S 24851-0103S
21 Cord Ring 1 24850-0008 24850-0009
22 Valve and Gauge Assembly
(Includes Key Nos. 1-5) 24850-0105
24850-0105
†• Lateral Extension Adapter as req'd 24700-0029 24700-0029
• Decal - Model Label 1 32155-4045 32155-4047
• Decal - Warning 1 32165-4004 32165-4005
• Decal - Operating Instruction 1 32155-4046 32155-4048
† Available for lateral repairs.
• Not illustrated
* Includes all decals and labels.
** Model S7S50 uses seven clamps and bolts; Model S8S70 uses eight.
REPAIR PARTS LIST
