STA-RITE U-3 - Repair Parts List; Part Identification; Suction Pipe Sizing Chart

3
3"
3"
3"
2" 2"
3"
2" 2"
6"
4,000 Sq. Ft. Pool
8 Skimmers
40 GPM Each
Main Drain
Main Drain
Minimum
3' Apart
Pool No. of
Surface Area Skimmers
Skimmer Rated Flow (GPM)
In Square Ft. Required 30 35 40 45 50
Up to 600 1 2"2"2"2"2"
1,000 2 2
1
/
2
2
1
/
2
2
1
/
2
2
1
/
2
2
1
/
2
1,500 3 2
1
/
2
3334
2,000 4 34444
2,500 5 44444
3,000 6 44445
3,500 7 44555
4,000 8 45555
4,500 9 45556
5,000 10 55566
5,500 11 55666
6,000 12 55666
Nom.
Pipe
Dia.
(In)
Chart I: Suction Pipe Sizing by Surface Area of
Pool and Rated flow Capacity of Skimmers
{
SWIMQUIP
1
2
3
5
4
8
7
6
1002 0694
9
Key. Public Pool Residential Pool
No. Part Description U-3 Models U-3 Models
White, w/2 x 1-1/2 NPT Reducers 08650-1403 08650-4403
White, w/2 x 1-1/2 Slip Reducers 08650-1404 08650-4404
Tan, w/2 x 1-1/2 NPT Reducers 08650-2403 08650-5403
Tan, w/2 x 1-1/2 Slip Reducers 08650-2404 08650-5404
Tan/Gray, w/2x1-1/2 NPT Reducers 08650-3403E –
Tan/Gray, w/2x1-1/2 Slip Reducers 08650-3404E –
Tan/Gray, w/2x1-1/2 NPT Reducers 08650-6403E –
Gray, w/2x1-1/2 NPT Reducers 08650-3403 –
Gray, w/2x1-1/2 Slip Reducers 08650-3404 –
1 Frame and Grate Kit (Tan) 08650-0159 08650-0159
1 Frame and Grate Kit (White) 08650-0169 08650-0169
2 Basket and Handle 08650-0007 08650-0007
• Basket Handle Only 08650-0067 08650-0067
3 Float Assembly w/O-Ring 08650-0079 –
4 Float O-Ring Only 35505-1273 –
5 Check Valve 08655-0017 –
6 Hinged Weir Assembly 08650-0022A 08650-0022A
• Weir Bumper 08650-0018 08650-0018
• Screw #8 x 3/8" 37207-0825 37207-0825
7 Screw #8 x 1/2" 37207-0027 –
8 Trimmer Plate 08650-0048 –
9 Vacuum Plate 08650-0042 –
REPAIR PARTS LIST
LIMITED WARRANTY
Skimmers manufactured by Sta-Rite are warranted to be free of defects in material and workmanship for one (1) year from date of installation.
The foregoing warranties relate to the original consumer purchaser (“Purchaser”) only. Sta-Rite shall have the option to repair or replace the defective prod-
uct, at its sole discretion. Purchasers must pay all labor and shipping charges necessary to replace the product covered by this warranty. Requests for war-
ranty service must be made through the installing dealer. This warranty shall not apply to any product that has been subject to negligence, misapplication,
improper installation or maintenance, or other circumstances which are not in Sta-Rite’s direct control.
This warranty sets forth Sta-Rite’s sole obligation and Purchaser’s exclusive remedy for defective products.
STA-RITE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL OR CONTINGENT DAMAGES WHATSOEVER.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES. IMPLIED WARRANTIES, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND BEYOND
THE DURATION OF THE APPLICABLE EXPRESS WARRANTIES PROVIDED HEREIN.
Some states do not allow the exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the
above limitations or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state
to state.
Supersedes all previous publications.
Sta-Rite Industries, 293 Wright St., Delavan, WI 53115
Figure 7: Multi-Skimmer Installation with pipe sizing.
Note multiple main drains.
