Stab HH120 - Page 9

L= 30 ÷ 60 m
18 Ω/km (max)
10 Ω/km (max)
Ø=1,02mm
Ø=1,13mm
22 Ω/km (max)
18 Ω/km (max)
8mm
15mm
3mm
A
B
C
D
E
G
H
L= < 30 m
Characteristics of the coaxial cable
Eigenschaften des Koaxialkabels
Caratteristiche del cavo cossiale
Caractéristiques du câble coaxial
Características del cable coaxial
F
ASSEMBLY
9
