Stage Light 612980 - DMX Control

6
* Perform the following steps to select a built-in effect (Shnd) and to set the speed at
which it executes.
1. Select the Shnd menu entry, then press the ENTER button.
2. Use the UP and DOWN buttons to select the desired effect from 01 to 24, then press
the ENTER button.
3. Select the Shnd menu entry again, then press the ENTER button.
4. Use the UP and DOWN buttons until the display shows SPed, then press the ENTER
button.
5. Use the UP and DOWN buttons to set the speed to a value between 01 and 08, then
press the ENTER button.
DMX CONTROL
7-Channel Mode
CH #
Value Range
Function
1
0-255
Motor 1 control (0° - 135°)
2
0-255
Motor 2 control (0° - 135°)
3
0-255
Master dimming (0 - 100%)
4
0-9
No strobe
10-255
Strobe speed (slow to fast)
5
0-7
No effect
8-17
Effect 1
18-27
Effect 2
28-37
Effect 3
38-47
Effect 4
48-57
Effect 5
