Stahl 8150/ - Electrical Capacity Table (Type 8150;1-0787-0480-230)

R. STAHL INC. 9001 Knight Road Houston, TX 77054 Tel.: (800) 782-4357 www.rstahl.com
Electrical Capacity Table
In hazardous (classified) areas, heat produced by current in the wire inside an enclosure is a concern. Therefore, the continuous current of each current carrying
conductor, the quantity and the size of the conductors inside a terminal enclosure need to be limited.
Type 8150/1-0787-0480-230...
Enclosure size in mm (inches), W x H x D: 787 x 480 x 230 (31.0 x 18.9 x 9.1)
16 14 12 10 8 6 4 3 2 1 1/0 2/0 3/0 4/0 250 300 400 500 600
5
10 94 185
15 70 138
20 32 68 153
25 38 79
30 49 110
35 31 70
40 48 128
45 34 80
50 22 58
60 33 87
65 24 65 162
70 51 90
80 32 54 110
85 26 43 77
90 36 61
100 24 41 77
110 29 51 171
115 24 43 90
125 31 57
150 27 51
175 26 52
200 28 62
225 33 63
250 34 84
300
350
380 52
400
Enclosure 8150/1-0787-0480-230…
Current
Amps
Wire size AWG
How to use the electrical capacity tables:
In the white area of the electrical capacity table, the permitted numbers of the current carrying conductors inside the enclosure are indicated
(in and out counts as two wires) depending on wire size and continuous current.
In the shaded area of the electrical capacity table, additional conductors/terminals are permitted up to space limit of the enclosure.
In the area with dark diagonal lines, no conductors are permitted.
Jumper links and ground wires can be neglected, in calculating the number of wires. These can be added whenever necessary.
Mixed circuits of different wire sizes and current values are possible by applying the table values proportionally.
Please refer to section 9.3.1 of 8150/1 Installation, Operating & Maintenance Sheet for more information.
