Technical Procedure
Page 2
620-8590 Rev. A
4. Remove the brake spring with a pair of needle
nose pliers and discard.
5. Use a 4mm allen key to remove the two (2) M8 x
20mm screws from the user left side handrail.
6. Use a 2.5mm allen key to remove the M4 x 8mm
screw located in front of the M8 screws removed
in Step 5.
7. Repeat Steps 5 + 6 for the user right side hand-
rail.
8. Once all the screws securing the handlebar to the
frame have been removed, remove the handle-
bar.
To Next Page
