8
ASSEMBLY INSTRUCTIONS
14. USE TWO 9/16” WRENCHES AND
REMOVE TWO BOLTS , FOUR FINISH
WASHERS, AND TWO NUTS FROM
HANDRAILS.
BOLT
FINISH WASHER
NUT
15. GET CONSOLE BRACKET FROM
CARTON AND POSITION OVER
HANDRAILS. INSTALL BOLTS, FINISH
WASHERS, AND NUTS TO SECURE
CONSOLE BRACKET TO HANDRAILS. USE
9/16” WRENCHES TO TIGHTEN BOLTS.
HANDRAIL
CONSOLE BRACKET
BOLT
FINISH WASHER
