Installation Instruction
Temporary Work Light
150 W LED Temporary High Bay
Fig. 1 Fig. 2 Fig. 3
INSTALLATION - STEPS
1. Turn OFF the power before proceeding with the installation.
2.Hangthe luminaire where desired, using the designated hook on the handle. Ensure that it can handle a
weight of 66 lbs. (Fig. 1)
3.Youmustusethesafetyropetotighttheluminaire.
4.Plugtheluminaireintotheoutletandturnonthepower(AC120V).TheLEDTemporaryHighBaycanbeturned
ON and OFF using the wireless remote control.
5.Closethecapifnoneedstodaisychainotherluminaires.(Fig.2)
6.Todaisychaintwo(uptofour)luminairestogether,openthecapandconnectthepluginthesocket.Once
thesecondluminaireispluggedintotherstone,rotatethebucklefromtherstluminaire,tomakesurethe
connectionismorerm.(Fig.3)
Wireless Remote
