Standard 710 - Page 10

Use of the Machine Part 1
Manual Controls - mechanical which can be operated when mechanism
running or stationary.
1 Toppiece Cutter Guide Screw
2 Band Alignment Screw x 2
3 Brush & Pad Turret Positioning handle
4 Dust Extraction Cover (710/730)
5 Optional Toppiece Scouring Roll Guide (fitted as standard on Model 720)
6 Old-style Adjustable Forepart Trimmer Adjustment Lever
