• Place the adjusting gauge with the side labeled “ Check Jog Table” facing down onto the rails,
first on the left edge of the jog table.
• Raise the adjusting screws at each corner until there is .01 in (3-20 lb. sheets of paper) space
between the bottom of the gauge and the jog table
• Repeat procedure to adjust th
e right side of the table.
• Check to ensure the space is even front, back left, and right.
• Remove the adjusting gauge and the jog table to tighten the
locking nuts. Then replace the jog
table.
• Bring the table back up to the raised position
• Insert the gauge as before and turn the adjusting screws (leave locking nuts tight) until the jog
table is just touching the adjusting gauge. Check to ensure that the gauge is not being lifted off
the rails.
• Adjusting one end of the table will affect the other, so it’s best to make this final adjustment in
two or three steps.
• Finally, with the table in its raised position and correctly adjusted, tap the left rear and right
front corners of the table with a finger. If a clicking sound is heard, the table bearings are not all
in contact with the table. The right front bearing and only the right front bearing
may be raised
or lowered to correct the rocking. Raise or lower until the rocking just stops. Then, recheck with
your gauge.
DRUM ADJUSTMENTS
This adjustment must be made with the drum hot and the machine in the “Ready” condition.
• Adjust the adhesive thickness to minim
um, then move the carriage to the left side of the
machine.
• Remove all adhesive from the top surface of the drum. Place the gauge with the s
ide labeled
"Check Drum” facing down onto the carriage rails and slide the gauge directly over the center of
the drum. CAUTION: DRUM AND TANK ARE VERY HOT.
• Adjust the two tank leveling screws, visible through the right end of the tank shroud, until the
drum just touches both legs of the gauge without lifting it off the rails. Do not
touch the single
screw at the opposite side of the tank.
The Bind-Fast 5 can drift out of alignment during shipping or especially after heav
y use. If this
happens, follow the instructions below or call your dealer for assistance. If re-alignment is
necessary, the following tools are required:
• An adjustment wrench
