Stander 8150 - Assembly Step 3: Attaching Support Arms; Assembly Step 4: Adjusting Handle Height

8150 Universal Stand Assist, V 2.1, October 25, 2021
3. First determine chair or couch depth and insert B into C as shown in FIGURE 3. Align the appropriate holes and insert
G, J and H and secure with F.
FIGURE 3
4. Insert E into C and align holes to desired handle height as shown in FIGURE 4. Insert G, J and H and secure with F.
FIGURE 4
