Stanley Fatmax SFMCBL7M1 User Manual

10
ENGLISH
Fuel Gauge Battery Packs (Fig. B)
Some STANLEYFATMAX battery packs include a fuel gauge
which consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge, press and hold the fuel gauge
button
9
. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level of
charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
Assembly (Fig. C)

CAUTION: Ensure the lock-off switch is in the locked
position to prevent the trigger switch from moving and
the battery is removed before attaching or removing the
tube assembly. The tube assembly must be attached to the
blower beforeuse.
TO ASSEMBLE BLOWER TUBES
1. Align the upper tube
4
to the blower and the lower tube
5
to the upper tube as shown in Fig. C.
2. Push the upper tube firmly onto the blower, until the lock
engages and an audible click is heard.
3. Then push the lower tube firmly into the upper tube, until
the lock engages and an audible click is heard.
4. Pull on the tubes to ensure they are securely in place.
NOTE: To remove either tube, insert a screwdriver into the
unlocking hole on the housing. Lift the tab inside and pull
tube out.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Proper Hand Position (Fig. A, D)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
Hold the handle
3
with one hand. as shown in Figure D.
Switching On (Fig. A, E)

CAUTION: Do not point unit discharge at self
orbystanders.

CAUTION: Always wear safety glasses. Wear a filter mask
if the operation is dusty. Use of gloves, long pants and
substantial footwear is recommended. Keep long hair and
loose clothing away from openings and movingparts.
1. To turn the blower on, depress the variable speed trigger
1
.
2. Release the trigger to turn the blower off.
Boost Button
The boost button
2
is located on the tool handle. It allows
you to optimize the tools performance and boost the power as
needed.
• Switch the sweeper on.
• To activate the “boost” mode, press the boost button down.
• To deactivate the “boost” mode, press the boost button down.
• Operate in “Normal” mode for most sweeping needs. (Longer
runtime will be achieved.)
• Activate “boost” mode as needed to clear heavy or wetdebris.
MAINTENANCE
Your STANLEYFATMAX power tool has been designed
to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon
proper tool care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than those offered by
STANLEYFATMAX, have not been tested with this product,
use of such accessories with this tool could be hazardous.
To reduce the risk of injury, only STANLEYFATMAX
recommended accessories should be used with
thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
