Stanley Omnilock 45HOM Installation Addendum

To ensure accurate door preparation, use only factory-
printed templates. Do not
use copies or facsimiles.
1/8 in
3mm
Horizontal centerline
of lock
Horizontal centerline
of lever
7/8 in
23 mm
3/8 in
10 mm
1/2 in
13 mm
3/16 in
5mm
Through hole
F
3/16 in
5mm
Through hole
C
H
B
Align to vertical centerline
Inside Door
F
D
D
J
K
1/8 in
3mm
H
1/8 in
3mm
1/8 in
3mm
J
1/8 in
3mm
J
1/8 in
3mm
J
3/4 in
19 mm
Hole Descriptions
B Thumb turn (1)
C Lever (1)
D
Trim mounting (2)
F
J
Thumb turn mounting screws (2)
H
K
Weatherized module bolts (4)
Module bolt (2)
Cables
Through hole
TV model only
3/8 in
10 mm
Vertical centerline
of lever
TV model only
7 29/64 in
189 mm
