No.
Code No.
Description
Specification
Qty.
Remark
1 GB/T13871-92 Framework oil seal VC 130*145-10 8
2 03.01049 Hexagon socket head cap screws M6×20 8 GB/T 70.1-2000
3 03.0011 Spring Washer Φ6 8 GB/T79-1987
4 1115-220000-0B Driving wheel 1
5
Z130D750-24A1-2
6.5S
Driving motor
24V
1
1.5t/1.8t
Z130BLD750-48A
1-30S
48V 2.
0t
6
JX6-2
Connecting box
1
7
GB/T1096-2003
Key 5*5*14 double round head
A type of Key
1
8 1115-200005-0B Small helical 1
9 GB/T276-94 Anti-friction bearing61824-2RS Φ120*Φ150*16 1
10 ZD-NL-571-001 Adjust Washer 40CR 1
11 GB/T 893.1-86 Circlip for hole Φ150 1
12 GB/T276-94 Anti-friction bearing61824-2RS Φ120*Φ150*16 1
13
1115-200002-0B-
X
Straight ring 20CrMnTi 1
14 GB/T13871-92 Framework oil seal
TCΦ155*Φ172*
10
1
15 ZD-SJ-504-001 BOX QT450 1
16 03.0013 Spring Washer Φ8 5 GB/T79-1987
17
03.0158
Hexagon socket head cap screws
M8×35
5
GB/T 70.1-2000
18
1115-200003-0B
Small straight tooth
1
19 GB/T1096-2003 Key 5*5*20double round head A type of Key 1
20
1115-200004-0B
Large tooth
1
21 GB/T276-94 Anti-friction bearing 61905-ZZ 1
22 ZD-RY-505-001 Box cover ADC12 1
23 GB/T13871-92 Framework oil seal TCΦ16*Φ28*7 1
24 03.0011 Spring Washer Φ6 8 GB/T79-1987
25 03.01049 Hexagon socket head cap screws M6×20 8 GB/T 70.1-2000
26 JB/T7940.1-1995
Straight-through injection oil
cup
1
27 GB/T119.1-2000 Locating pin 5*15 1
28 GB/T1096-2003 Key 5*5*8double round head A type of Key 1
29 ZD-NL-571-002 Brake hex 1
30 GB/T894.1-86 Circle for shaft Φ15 1
31
ZD-HZDC-362-001
6N.M Brake
1
32 ZD-ZJNL-076-001 Brake plug 1
DRIVING ASSEMBLY
