4
FUEL TANK CAP
FUEL TANK
HANDRAIL
ENGINE ON/OFF SWITCH
LIFT HANDLE
LIFT FRAME
BELLOWS
WHEEL KIT FRAME
FOOT PLATE
ENGINE SUPPORT
GEAR BOX
ENGINE
FEATURES AND SPECIFICATIONS
Compact the areas that you would like to work on with the STKUSA Compact Jumping Jack. This machine
allows you to condense the ooring that you would be working on to help give the oor a rm and compact
area for the material to sit atop. Create a rm ground in your home,yard, or street to help you place
ooring that will not become loose and have perfect tting on the oor.
Ideal for compacting gravel, clay and sand in compactness of road, bridge foundation, house, reservoir
dam, and narrow worksite
Ramming Plate Size: approx. 300 mm x 300 mm; Percussion Rate (Ramming Frequency): 450~650
Times per Minute
Engine Power: 6.5 HP 4 Stroke Recoil Start; Jumping Stroke (Leap Height): 40~65mm
Impact Force Also Known “Ramming Force”: 10,000N
EPA & CARB Approved
FEATURES
