TRAMPOLINE AND ENCLOSURE PARTS LIST
9
Enclosure
Part
Number
Diagra
m D
escription
Quantity
A
Up
per Frame Tube w
ith Foam 4
B Lower Frame Tube with Foam 4
C1
Flat Ste
el Plate 8
C2
Flat Steel S
ockets 8
D
Wrench 1
E
Self-Locking Screw 8
F
Cord 6
G
Enclosure Netting
1
H
Bolt (12mm
) 16
I
Cap Nut 16
J
Trampoline Enclosure Safety Instruction
Placard
1
K
Plastic
cap 4
GEN-ENCTUB-UP
GEN-ENCTUB-LOW
GEN-FLATSOCK
GEN-SPAN5-11-13
TR120-FLSTPLA
TE104CM
GEN-
S
CRW-M4X15
GEN-CORD1
TR120-ENCNET-GRE
GEN-CAPNUT-M5
GEN-BOLTM5X12
GEN-STF-ENCPOLEND
