Declaration of Conformity
ENGLISH
9
9
Technical Data
Screwdriver 384B
Power input
600
No-load speed
0-4500
Max. screw dia.
mm
Tool holder
Hexagonal
Weight
1,8
Protection class
/ II
W
kg
/min
The values given are valid for nominal voltages [U]
230/240 V ~ 50/60 Hz - 110/120 V ~ 60Hz. For lower
voltage and models for specific countries, these values
can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual
machines may vary.
Assembly
Changing the Tool
Pull off the screwing-depth stop 4 toward the
front. Pull out the screwdriver bit 1. If required,
the universal bit holder 9 can also be pulled off
and replaced.
After changing the tool, reattach the screwing-
depth stop 4.
Operation
Starting Operation
- Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specified on the nameplate of the
machine. Power tools marked with 230 V can
also be operated with 220 V.
Reversing the Rotational Direction
The rotational direction switch 8 is used to
reverse the rotational direction of the machine.
However, this is not possible with the On/Off
switch 7 actuated.
Right rotation: For driving in screws, push the
rotational direction switch 8 left to the stop.
Left rotation: Push the rotational direction
switch 8 right to the stop (for unscrewing
screws).
Switching On and Off
To start the machine, press the On/Off switch 7
and keep it depressed.
To lock the pressed On/Off switch 7, press the
lock-on button 6.
To switch off the machine, release the On/Off
switch 7 or when it is locked with the lock-on but-
ton 6, briefly press the On/Off switch 7 and then
release it.
Adjusting the Speed
The speed of the switched on power tool can be
variably adjusted, depending on how far the
On/Off switch 7 is pressed.
Light pressure on the On/Off switch 7 results in
a low rotational speed. Further pressure on the
switch results in an increase in speed.
Adjusting the Screw-in Depth
With the adjustment sleeve 3, the screw-in depth
of the screw head into the workpiece can be pre-
set in 12 locking steps per full turn. Each step cor-
responds with a 0.125 mm change of the screw-in
depth.
We declare under sole responsability that this
product is in coformity with the following standards
or standardisation documents:
EN 60745, according to the provisions of the
directives 2006/42/CE, 2004/108/CE, 2006/95/CE
Ramiro de la Fuente
Director Manager
6,3
