Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH36LB-D3DNA5G/I GWH36QF-D3DNB4G/I
Product Code CB169N01002 CB434N04901
1 Receiver Window / / /
2 Front Panel
20012661 CB434N04901 1
3 Stand bar
24212120 24212120 1
4 Filter Sub-Assy
11122106 11122106 2
5 Front Case Sub-Assy
20022159 20900700005 1
6 Upper Guide Louver
10512166 1051216601 1
7 Lower guide louver
10512167 1051216701 1
8 Axile Bush
10542704 10542704 6
9 Air Louver 2
10512169 1051216902 2
10 Air Louver 1
10512168 1051216802 16
11 Connecting Rod
10582086 10582086 2
12 Louver Clamp
26112158 26112158 9
13 Water Tray
20182138 2018213802 1
14 Screw Cover
242520053 2425200506 4
15 Rubber Plug (Water Tray)
76712012 76712012 1
16 Rear Case Sub-Assy
22202928 22202928 1
17 Cross Flow Fan 1
10352039 10352039 1
18 Bearing Holder sub-assy
26152028 26152028 1
19 Cross Flow Fan 2
10352040 10352040 1
20 O-Gasket sub-assy of Bearing
76512051 76512051 1
21 Left Evaporator Support
24212041 24212041 1
22 Evaporator Assy
01002000027 01002000027 1
23 Wall Mounting Frame
01252398 01252398 1
24 Right Support of Evaporator
2421204201 2421204201 1
25 Fan Motor
1501213401 1501213401 1
26 Pipe Clamp 26112071 26112071 1
27 Drainage hose
0523001404 0523001404 1
28 Fixed Clip (Evaporator)
02112009 02112009 1
29 Cover Plate
20122124 2012212402 1
30 Motor Fixed Clip
26112324 26112324 1
31 Step Motor
1521210701 1521210701 1
32 Press plate (crank)
26112070 26112070 1
33 Crank-guide
10582041 10582041 1
34 Upper Crank
10562004 10562004 1
35 Lower crank
10562005 10562005 1
36 Electric Box Assy
10000204522 10000204114 1
37 Electric Box
201022502 201022502 1
38 Terminal Board
42011233 42011233 1
39 Main Board
30138001017 30138001017 1
40 Display Board
30565124 30565277 1
41 Electric Box Cover
201022523 201022523 1
42 Electric Box Cover
2011204404S 2011204404S 1
43 Remote Controller
305001000092 305001000085 1
44 Tube Sensor
390000592 390000453 1
45 Ambient Temperature Sensor
390000453 390000592 1
46 Detecting plate(WIFI)
30070077 30070079 1
INTENTIONALLY BLANK
73
