Description
Part Code
Qty
SC-36ZPL-HP230
Product Code CB432N08101
1 Front Panel 20000300022S 1
2 Stand Bar 2421212001
1
3 Filter Sub-Assy 11122106
2
4 Front Case Sub-assy 20900700005
1
5 Upper Guide Louver 1051216601
1
6 Lower Guide Louver 1051216701
1
7 Axile Bush 10542704
6
8 Air Louver 2 1051216902
2
9 Air Louver 1 1051216802
16
10 Connecting Rod 10582086
2
11 Louver Clamp 26112158
9
12 Water Tray 2018213802
1
13 Screw Cover 2425200506
4
14 Rubber Plug (Water Tray) 76712012
1
15 Rear Case assy 00000100113
1
16 Cross Flow Fan 1 10352039
1
17 Bearing Holder Sub-assy 26152028
1
18 Cross Flow Fan 2 10352040
1
19 O-Gasket sub-assy of Bearing 76512051
1
20 Left Evaporator Support 24212041
1
21 Evaporator Assy 1002000027
1
22 Wall Mounting Frame 1252398
1
23 Fan Motor 1501213401
1
24 Pipe Clamp 26112071
1
25 Drainage Hose 523001404
1
26 Cover Plate 2012212402
1
27 Motor Fixed Clip 1 26112324
1
28 Stepping Motor 1521210701
1
29 Press Plate(Crank) 26112070
1
30 Crank-guide 10582041
1
31 Upper Crank 10562004
1
32 Lower crank 10562005 1
33 Electric Box Assy 100002001022
1
34 Electric Box 201022502
1
35 Terminal Board 42011233
1
36 Main Board 30138001017 1
37 Display Board 30565277 1
38 Electric Box Cover 2011204404S
1
39 Electric Box Cover 2011204404 1
40 Remote Controller 305001000085
1
41 Temperature Sensor 390000592 1
42 Temperature Sensor 390000453 1
43 Detecting plate(WIFI) 30070077
1
