Description
Part Code
Qty
SC-36ZPL-HP230
Product Code CB432W10100
1 Front Grill 01574106
1
2 Cabinet 01435007P
1
3 Axial Flow Fan 10335014
1
4 Drainage hole Cap 76715005
1
5 Electrical Heater (Chassis) 7651000413
1
6 Drainage Joint 26113009
1
7 Clapboard Sub-Assy 0124525304
1
8 Magnet Valve Sub-assy 030025000055
1
9 Magnet Valve Sub-assy 030025000056
1
10 Inhalation Tube Sub-assy 030010000570
1
11 Compressor and Fittings 00204100030
1
12 Electrical Heater(Compressor) 7651873209
1
13 Accumulator 07424100031
1
14 Electronic Expansion Valve assy B 030174000139
1
15 Right side plate 017038000055
1
16 Valve Support Sub-Assy 01805200222P
1
17 Cut off Valve Sub-Assy 030057000153
1
18 Valve Cover 22245005
1
19 Cut off Valve 07133157
1
20 Handle 2623305301
1
21 Handle Assy 02113109
1
22 Gas-liquid Separator 07223048
1
23 4-Way Valve Assy 030152000370
1
24 Baffle Plate Sub-ass 01355200016P
1
25 Electronic Expansion Valve assy A 030174000138
1
26 Temperature Sensor 3900007201
1
27 Rear Grill 01475012
1
28 Condenser Assy 011002000628
1
29 Top Cover 0125500901P
1
30 Motor Support Sub-Assy 017012000155
1
31 Left Side Plate 01305064P
1
32 Main Board 300027000042
1
33 Electric Box Sub-Assy 017007000632
1
34 Radiator 43003400001601
1
35 Terminal Board Support sub-assy 01715016
1
36 Terminal Board 42000100000402
1
37 Electric Box Assy 100002003294
1
38 Brushless DC Motor 15010400000106
1
