Page 23
INSTALLATION & USER GUIDE
INSTALLING LIGHT
CAUTION! Installer must take some moisture proof measures in the process of installation. Electrophorus components cannot be
exposed to moisture, as it will cause damage to the light components causing a possible short circuit.
INSTALLING SPEAKERS
1. Chose a proper place on ceiling inside the steam room.
2. Open 4 holes with 5mm depth and 100mm diameter.
3. Fix the speaker and grill on the ceiling with the provided screws as pictured.
4 5 mm
Rubber Gas ket
Tighten N ut
LED light
Ceiling of steam room
speaker
grill
ceiling
screw
speaker
90°
90°
Ø4.58”
Ø3.9”
Ø4 to 7 holes
